Meanwell Power Supply WDR-480-48

• Output Voltage: 48 V DC

• Rated Output Current: 10 A → 480 W total power

• AC Input Voltage Range: 180–550 VAC (single or two-phase) and DC input support up to ~780 VDC

• Efficiency: Approximately 93%

• Operating Temperature: –30 °C to +70 °C (with derating at extreme low input)

• Protections & Features: Includes short-circuit, overload, over-voltage, and over-temperature protection; built-in active PFC; DC‑OK relay contact; 100% full-load burn-in; convection cooling (no fan)

• Certifications: UL508 industrial control, CE, CB, EN61000‑6‑2 EMC industrial immunity standards

• Mounting Format: DIN‑rail TS‑35/7.5 or 15; enclosed slim metal case (approx. 128.5 × 85.5 × 125.2 mm; ~1.7 kg weight)

⚙️ Model Comparison: WDR‑480‑24 vs. WDR‑480‑48
