PKM-0250-XL0327
₹9,657.00
Brand: Gefran-
Type: Potentiometric rodless linear displacement sensor
-
Stroke Length: 250 mm (useful electrical stroke)
-
Linearity: ±0.05%
-
Repeatability: 0.01 mm
-
Displacement Speed: Standard ≤ 10 m/s
-
Protection: IP65
-
Vibration Resistance: 5–2000 Hz, Amax = 0.75 mm, max. = 20 g
-
Shock Resistance: 50 g, 11 ms
-
Acceleration Resistance: 200 m/s² max (20 g)
-
Maximum Applicable Voltage: 60 V
-
Mounting: M5 thread mechanical linkage joint with play compensation
-
Applications: Ideal for plastic injection presses, vertical presses, and various processing machinery
-
Output: Linear voltage output proportional to displacement
-
Installation: Designed for easy installation with minimal electrical signal variation outside the theoretical electrical stroke
-
Manufacturer: Gefran
