DP-102-E-P

Display: Dual 4-digit, 3-color LCD (simultaneous current + set value)

Pressure range: –0.101 to +1.010 MPa (–1.01 to +10.10 bar / –14.6 to +146.4 psi)

Rated pressure: 1 MPa (withstand up to 1.5 MPa)

Outputs: 2 × PNP open-collector, 100 mA max each @ 30 V DC

Output modes: Easy / Hysteresis / Window comparator

Response time: Selectable 2.5 ms to 5,000 ms

Repeatability: ±0.2% F.S.

Temp. drift: ±0.5% F.S. at +20 °C

Supply voltage: 12–24 V DC (±10%)

Power consumption:

• Normal: ≤ 30 mA (~720 mW)

• Eco STD: ≤ 20 mA (~480 mW)

• Eco FULL: ≤ 15 mA (~360 mW)

Protection rating: IP40

Operating temp.: –10 to +50 °C

Humidity: 35–85% RH

Pressure ports: M5 female + G1/8 (Europe) or R1/8 (Asia)

Materials: PBT body, acrylic display window, SUS303 stainless steel port, nickel-plated brass fitting

Dimensions / weight: Compact, ~40 g (main unit)

Vibration resistance: 10–500 Hz, 3 mm amplitude (196 m/s²)

Shock resistance: 10 G (100 m/s²), 3× each axis

Certifications: EMC, RoHS
