HL-G208B-A-MK

₹107,321.00

Brand: Panasonic

Type: CMOS laser displacement sensor (compact)
Sensing Range: 20 ±8 mm (12–28 mm)
Linearity: ±0.1 % F.S. (±0.02 mm)
Repeatability: 1 µm
Light Source: Red semiconductor laser, Class 2
Output: Analog voltage (0–5 V) + Analog current (4–20 mA) + RS-422/RS-485 digital interface
Response Time: 1 ms / 2 ms / 5 ms / 10 ms / 20 ms (selectable)
Display: OLED digital display
Power Supply: 12–24 V DC ±10%
Connection: Dedicated connector type
Operating Temp: 0°C to +50°C
Protection: IP67
Use: High-precision displacement/thickness/position measurement in semiconductor, electronics & precision machinery
